Product Description

With simple operation and rapid response time, PMB moisture analysers offer the top value in their class. The automatic test-setting function enables easy recall for frequent testing of the same items without additional user programming. USB and RS-232 interfaces provide computer and printer connections to store test programs and results. No additional software is needed to take readings, giving users total freedom to collect data on a production floor or in the field. A single 400-watt halogen bulb heats samples in 1 °C selectable increments. Three heating options give users the flexibility to customise test methods and temperatures for different materials.

Features & Benefits:

Hardware –

  • Scratch-resistant aluminum housing protects internal components
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Pan lifter allows easy placement and removal of samples
  • RS-232 interface is available to provide speedy connection to computers and printers
  • USB host for memory card and USB I/O interface
  • USB interface included for data communication
  • Temperature range 50°C to 160°C in one-degree increments


Software –

Three settings for heating sample include ramp-up, stepped temperatures and single temperature

Seven preset drying modes allow test routines for several products

Audible overload alarm warns when capacity is exceeded

Testing can be set to start automatically when lid closes

Calibration for temperature and weight

Multilingual display allows use in many different countries

Quick and easy configuration using the keypad

Zero-tracking feature ensures display returns to zero reading

Internal memory stores 49 different receipes and up to 99 test results,

and additional test results and settings can be stored on a flash drive.

Power –

            • Mains power cord

Display –

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Programmable backlight can be set to “always on,” “always off” or “light only when weighing”
  • Capacity tracker built into display for easily monitoring possible overloads





To Download the PMB 202 Manual

Please Click Here
