WiFi-Alert Audible and Visual Alarm

• Detects alarms from FilesThruTheAir™ WiFi sensors on the same wireless network
• Works at all times including when the PC is turned off
• Audible alarm with built-in speaker (SPL 100dBA @1m) with configurable alert tones and volume
• Visual alarm from high brightness LEDs
• Easy set-up using the free PC software application

The WiFi-Alert is a standalone monitoring system for all sensors in the FilesThruTheAir™ WiFi range. The Alert will receive alarm messages from any FilesThruTheAir™ WiFi sensor connected to the same wireless network. The WiFi-Alert indicates an alarm activation using high brightness LEDs and a choice of 9 alarm tones. Position the Wifi-Alert close to those that will need to respond to the alarm e.g. an office or monitoring centre. This means that the Alert doesn’t need to sit next to the sensor/s that it is monitoring as long as they are connected to the same wireless network.

The WiFi-Alert has been designed to be continously powered via the mains however it does contain a rechargeable lithium polymer battery for device positioning and limited power during the event of a mains failure.

The audible and visual WiFi signal strength indicator is activated by pressing the WiFi-Alert button three times. All LEDs and a fast beep indicate a strong signal. Limited LEDs and slow beep indicate a weak signal.

The audible alarm can be muted by pressing the WiFi-Alert button once or remotely from the PC software.

After initial set-up audible and visual alerts can be reconfigured wirelessly from the PC software. This software is available to download for free from the Support page. Free firmware downloads are also available.

The device is IEEE 802.11b compliant, supports WEP, WPA/WPA2 and Enterprise encryption, and has a protection rating of IP44 (with cable connected).

The WiFi-Alert can be attached to a wall or flat surface using the bracket or adhesive pad provided. It is also supplied with a micro USB lead and mains charger.

The operating temperature range for this product is -20°C to +60°C. However, when powered by mains or charging the operating temperature range is 0°C to +40°C.
