Propylene Glycol Refractometer 0-100%
HI 96832 Propylene Glycol Digital Refractometers is a rugged, portable, water resistant devices that utilize the measurement of refractive index to determine the percent volume and freezing point of propylene glycol based solution.
These digital refractometers eliminate mechanical refractometer uncertainty. HI 96832 sample is measured after a simple user calibration with distilled or deionized water. Within seconds, the refractive index and temperature are measured and converted into one of two measurement units; % Volume or Freezing Point.
HI 96832 utilize internationally recognized references for unit conversion and temperature compensation for glycol solutions (e.g. CRC Handbook of Chemistry and Physics, 87th Edition).
|Range||0 to 100 %Volume0 to -51 °C (32 to -59.8 °F) Freezing Point|
|Resolution||0.1 %Volume0.1 °C (0.1 °F) Freezing Point|
|Accuracy||±0.3 %Volume ±0.5 °C (±1.0 °F) Freezing Point|
|Automatic Temperature Compensation||between 10 and 40°C (50 – 104°F)|
|Measurement Time||Approximately 1.5 seconds|
|Minimum Sample Volume||2 metric drops|
|Light Source||Yellow LED|
|Sample Cell||Stainless steel ring and flint glass prism|
|Battery Type / Life||(1) 9V / 5000 readings|
|Auto-Off||After 3 minutes of non-use|
|Dimensions||19.2(W) x 10.2(D) x 6.7 (H)cm|
