Product Description

Product detail

The data monitoring system testo Saveris measures the temperature and humidity values of sensitive goods and products in the environment, in processes and during transport. The easy-to-use measurement system delivers safety and savings in time and costs thanks to automated measurement data recording.

In stationary operation, the transfer of the measurement data takes place via wireless and/or Ethernet connection to a base station. This documents and monitors all measurement data. If limit values are exceeded, a whole range of different alarm options, such as SMS/e-mail alarm or alarm relay is available. Remote alarms can even be given when the system is not connected to a running PC. testo Saveris works in many countries with a radio frequency of 868 MHz.

The base is the heart of testo Saveris and can save 40,000 readings per measurement channel independently of the PC. This corresponds to around one year of memory capacity at a measuring rate of 15 minutes. – large internal store – Alarm via LED, relay – Display of system data and alarms – Energy supply via mains, additional emergency battery for data security

€¢graphical display, 4 control keys
€¢Up to 150 probes can be connected
€¢Interfaces: radio, Ethernet, USB
€¢Please notice: No mains units or antennas with magnetic base are contained in this ordering data.

(As this instrument is configured to your application, please call our Technical Sales Team for more information on 01436 831 065, Quotations available upon request)

Technical Data
Memory 40,000 values per channel (total max. 18,000,000 values)
Dimensions: 225 x 150 x 49 mm
Weight: Approx. 1510 g
Protection class: IP42
Material/Housing: Diecast zinc / plastic
Radio frequency: 868 MHz / 2.4 GHz
Power supply (absolutely necessary): 6.3 V DC mains unit; alternatively via 24 V AC/DC plug-in/screw terminals, power consumption < 4 W
Rech. batt.: Li-ion battery (for data back-up and for emergency SMS if power supply fails)
Oper. temp..: -10 … +50 °C
Storage temp..: -40 … +85 °C
Display: graphical display, 4 control keys
Interfaces: USB, radio, Ethernet
Connectable radio probe: max. 15 probes can be directly connected via radio interface, max. 150 total via radio / router / converter / Ethernet / Extender, max. 450 channels
Alarm relay: max. 1 A, max. 30 W, max. 60/25 V DC/AC, NC or NO contact
Set up: Table base and wall bracket included
